24. Zundapp 529 Rear wheel hub 120MM

• Spokes set
• For model with small hub (17 Inch - 120MM)
• 36 Pieces inner & outer spokes
• Length of the spoke is 181MM
• Chromed spokes including nipples
• Zundapp


• See images for sizes

• Wheel hub
• To use for the Front & Rearside
• Zundapp 120MM
• "Small Hub"
• Including bearings

• Sprocket rubber
• Good fit!
• Fits on a Zundapp Old model
• Small rubbers
• Sizes; 11X19.4X12MM


• Note, these go per piece!

• Rear axle
• Stainless Steel
• Zundapp

• M12x1.25
• Length 167MM

• Rear wheel axle
• Zundapp
• Key width 14MM
• 12MM
• Length 164MM

• Spacer Rear wheel Right
• Galvanized
• Zundapp

• Circlip
• Zundapp 517
• Front & Rear Hub ( 120MM - Small model )


• See extra images

• Bearing SKF
• 6201 2RS
• Inner diameter 12MM
• Outer diameter 32MM
• Width 10MM

  Is used for:
• Kreidler front wheel Left + Right
• Kreidler rear wheel Left + Right
• Zundapp 3 Gears. Front + Rear wheels (spoked)
• Zundapp Sprinter Front + Rear wheels (12 spoke cast wheels)
• Enfield Explorer
• Kreidler Flory MF23
• Wheel bearing Tomos A35

• Rebuild kit Ø 120MM hub
• 4 Pieces

  Set contains:
• 2x 6201 2RS bearings
• 1x Spacer
• 1x Circlip

  Fits on:
• Zundapp 510 (Model 1962)
• Zundapp 515
• Zundapp 517
• Zundapp 529

• Hollow axle
• Including nut
• Old type


• Zundapp 517



• Spacer Rear wheel
• Left
• Zundapp


• See images for sizes



Chain tensioner Zundapp.

Model: Round hole Right

Identical to zundapp article number
Z529-15.711

Chain tensioner Left

• Zundapp 517

Identical to zundapp article number
Z433-15.632

Hollow axle nut

• Zundapp

• Sprocket carrier / Hub flange
• Small hub 120MM

  Fits on:
• Zundapp 517
• Zundapp 529



• M8 Spring washer
• Stainless Steel
• Din 127B

• M8 Nut
• Stainless Steel
• Din 934
• A piece

• Bearing SKF
• 6203 2RS
• Inner diameter 17MM
• Outer diameter 40MM
• Width 12MM
  Is used for:
• Zundapp sprocket carrier

• Cover plate set for sprocket carrier
• 3-Pieces

  Set contains:
• 1x Cap (433-15.121)
• 1x Felt ring (433-15.119)
• 1x Cover plate (433-15.117)

  Fits a.o:
• Zundapp 517
• Zundapp 529
• Zundapp 530

M6 Nut
Stainless Steel.
Din 934

• Hex bolt
• M6X30
• Stainless Steel
• Full thread
• Din 933

Brake shoes

• Zundapp
• For small hub (120MM)
• Both front and rear

Brake shoes set

• Zundapp
• For small hub
• A-Quality / Newfren
• 120MM
• Note, a minor adjustment may be required before mounting

Washer Brake key.

• Zundapp

Identical to Zundapp article number
Z267-05.597

O-Ring Clutch Lever.

• Zundapp

Identical to Zundapp productnumber
405-15.388

• Brake lever
• Rearside
• Short model
• Zundapp 517


• Nut
• Brake key Zundapp all models
• M8 - Low nut
• A Piece
• See extra image

Rear sprocket

• Zundapp.
• 41 Teeth.
• Stitch 3/16 (Normal)
• Use a 415 Chain.

• Chain
• Wippermann
• 415 ( 3/16 )
• 122 Links
  Suitable for;
• Tomos A3/A35

Chain link

• Wippermann
• 415 ( 3/16 )
