Exploded view | Kreidler gearbox 5G Direct

Grouped product items
Product Name	Qty
2 - Shimring Clutch axle Kreidler 12X18X0.10 MM Shimring Clutch axle Kreidler. Size; 12 X 18 X 0.10 MM €0.89
2 - Shimring Clutch axle Kreidler 12X18X0.30 MM Shimring Clutch axle Kreidler. Size; 12 X 18 X 0.30 MM €0.89
3 - Clutch Pressure Pin Kreidler 4/5 G Long Clutch Pressure pin Long ( 91MM ) Kreidler 4 & 5 Gears €13.95	Out of stock
4 - Ball Kreidler Clutch A piece Ball Clutch . Kreidler. Price is a piece. Identical to Kreidler article number 00.69.28 €0.25

12 - Circlip Kreidler 20MM Main Axle Circlip Mainaxle Kreidler €0.35
12 - Circlip Kreidler 15MM Behind Front Sprocket Circlip Kreidler 15MM for behind the Front Sprocket. Kreidler €0.25
14 - Spacer fork ( Shift fork ) Kreidler Spacer fork Kreidler 4/5 Gears €47.95	Out of stock
15 - Pin for spacer fork Kreidler Pin for spacer fork Kreidler €12.95
16 - Front sprocket Kreidler RS 1/4 15 Teeth Front sprocket 15 Teeth 1/4 ( 420 ) Wide sprocket Flat side inside 11MM Kreidler RS 5 Gears €9.90
16 - Front sprocket Kreidler RS 1/4 13 Teeth Front sprocket 13 Teeth 1/4 ( 420 ) Wide sprocket Flat side inside 11MM Kreidler RS 5 Gears €9.90
16 - Front Sprocket Kreidler 5 Gears 3/16 12 Teeth Front Sprocket . Kreidler 5 Gears. Stitch 3/16 ( Small for 415 Chain ) 12 Tands Flat inside 11MM €8.50
16 - Front Sprocket Kreidler 5 Gears 3/16 14 Teeth Front Sprocket. Kreidler 5 Gears. Stitch 3/16 ( Small for 415 Chain) 14 Teeth Flat insidee 11MM €8.50
16 - Front sprocket Kreidler RS 1/4 12 Teeth Front sprocket 12 Teeth 1/4 ( 420 ) Wide sprocket Flat side inside 11MM Kreidler RS 5 Gears €9.90
16 - Front sprocket Kreidler RS 1/4 14 Teeth Front sprocket 14 Teeth 1/4 ( 420 ) Wide sprocket Flat side inside 11MM Kreidler RS 5 Gears €9.90
16 - Front Sprocket Kreidler 5 Gears 3/16 13 Teeth Front Sprocket . Kreidler 5 Gears. Stitch 3/16 ( Small for 415 Chain) 13 Tands Flat inside 11MM €8.50
17 - Securing plate front sprocket Kickstart Kreidler Securing plate front sprocket 10MM Kreidler For models with kickstart engine €1.15
18 - Front Sprocket Nut Kreidler Kickstartblok Front Sprocket Nut M10X1 Kickstartblok. Kreidler Identical to Kreidler article number 15.60.10 €0.50
20 - Shift fork Left Kreidler Direct transmission Shift fork Left Kreidler Direct transmission €97.95
21 - Gear fork Right Kreidler 5G Original Shift fork Right with pin 5 gears Kreidler Original €129.00
24 - Ring Shiftdrum Kreidler Direct Shimring for shiftdrum direct 12X25X0.5 Kreidler €2.95
24 - Shimring 12X18X0.1 Din 988 Shimring 12X18X0.1 Din 988 €0.89
24 - Shimring 12X18X0.3 Din 988 Shimring 12X18X0.3 Din 988 €0.89
